England BSI approval BS 1363 UK AC power cord 13A 250V 2 Pin Plug With Fuse
Product Details:
Quick Details
Place of Origin:Guangdong, China
Brand Name:BOH
Type:AC Power Cord, AC Power Cord
Application:Consumer Electronics
Male End Type:CEI
Female End Type:IEC
Product name:UK power cord
Color:Black
Material:Copper
Jacket:PVC
Meters:1.0m/ 1.5m/ 1.8m/ 2.0m
Certification:BSI
Length:1.2M/1.5M/1.8M/2M/3M(OEM)
Conductor:3*0.5mm2/3*0.75mm2/3*1mm2
Plug:2Pin
Specifications
| LABEL | VALUE |
| Connector Standard: | BSI 1363/A |
| Maximum Current rating: | 3A,5A,7A,10A,13A |
| Maximum Voltage: | 250V |
| Number of Poles and Wires: | 2 poles, 2 wires |
| Copper Conductor Material: | Oxygen free Copper (OFCU) |
| Outer Jacket Material: | PVC, Rubber, Halogen-Free, Textile braid |
| Blade Material: | Nickel coated Brass |
| Flamability Rating: | UL 94V-0 |
| Color: | Black/White/other |
| Temperature Rating: | -40℃ ~+75℃ |
| Approvals: | ASTA |
| Environmental Certifications: | RoHS, REACH, PAHs |
| Testing: | Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity |
| Country of Origin: | Made In China |
| Packing: | Standard Export Carton |
Available Wire Styles
| Gauge/ # Conductors | Cord Type |
| 2×0.5mm² | H03VV-F, H03VVH2-F |
| 2×0.75mm² | H03VV-F, H03VVH2-F, H05VV-F, H05VVH2-F, H05RR-F, H05RN-F, H03RT-H |
| 2×1.0mm² | H05VV-F, H05VV-F, H05RR-F, H05RN-F, H03RT-H |
| 2×1.5mm² | H05VV-F, H05VV-F, H05RR-F, H05RN-F, H07RN-F, H03RT-H |
| 3×0.5mm² | H03VV-F |
| 3×0.75mm² | H03VV-F, H05VV-F, H05RR-F, H05RN-F, H03RT-H |
| 3×1.0mm² | H05VV-F, H05RR-F, H05RN-F, H03RT-H, H07RN-F |
| 3×1.5mm² | H05VV-F, H05RR-F, H05RN-F, H03RT-H, H07RN-F |
